Model: KEYRACK
Intelligent KeyRack with key identification for
monitoring and controlling each and every key.
Space for a maximum of 924 key slots
(maximum of 66 key strips with 14 spaces
on each strip).Display with simple menu
navigation. Equipped with battery backup,
alarm contact for door and buzzer.
Intelligent KeyRack with key identification for monitoring and controlling each and every key. Space for a maximum of 924 key slots (maximum of 66 key strips with 14 spaces on each strip). Display with simple menu navigation. Equipped with battery backup, alarm contact for door and buzzer. Administration performed using the PC program KeyWin5. Can be expanded using multiple Key-Rack in the same system.
Users
Keys
Administrators
|
Key Rack
|
Designed to accommodate between 14 and 924 keys (or key sets), the innovative Key-Rack Series design allows for starting small and later expanding by adding multiples of 14 key positions (called expansion key strips) as required. Expansion Key Strips are defined as locking receptor strips lock the key fobs in place restricting access to authorized personnel down to the individual key. LED lighting indicate which keys can be taken, which keys are restricted and assist the user when returning the key to the correct location.The control pad consists of the user interface which includes the screen, keypad and access card or biometric reader.
![]() |
![]() |
The Key-Rack Series can support any type of access control device required to identify a user to the key system. Supported devices include RFID proximity readers from all leading access control manufacturers, magstripe, barcode and biometric technologies such as fingerprint, etc.
The Key-Rack is administered from the user friendly KeyWin 5 Pro software supporting a Microsoft Access or SQL database. The Key-Rack Series can communicate with the KeyWin 5 Pro software using a range of different options including Ethernet, GPRS, RS232 and modem. Multiple systems can be networked together over a local or wide area network to provide accountability for a limitless number of keys administered from multiple PC workstations running the KeyWin 5 Pro software
