Key-Box 9500 SC Series

Model: 9500SCSERIES

Intelligent Key Box with key identification for monitoring and controlling each and every key 24/7. Key-Box 9500 SC series offer a choice beteen 14, 28, 42, 56, 70, 84, or 98 key slots within the same cabinet. The system can be futher expanded up to 588 key slots with available expansion cabinets and expansion key strips. There is a wide range of options and accessories available for the 9500 SC sereis key system.

Key-Box High Quality Key Management Systems

Key-Box 9500 SC Series

Intelligent Key-Box with key identification for monitoring and controlling each and every key, Space for a maximum of 98 key slots (maximum of 7 key strips with 14 key slots on each strip). Display with simple menu navigation. Equipped with battery backup, alarm contact for door and buzzer. Administration performed by using the PC program KeyWin 5 Pro. The system can be expanded using multiple key cabinets in the same system up to 588 key slots using available 9500 EC expansion cabinets that can hold up to 98 key slots in each expansion cabinet, The expansion key cabinets are expanded with available expansion 14 key slot key strips. The 9500 SC series key management system is our most popular model and is in use throughout North America in all sorts of facilities and businesses. Our key systems are the lowest priced automated key systems in the market. Please download the PDF 9500 SC information brochure for more details and operation of the system.

Key-Box exclusive Secure-Lock 100% solid metal intelligent key fobs is the solid choice when it comes to choosing a key system. The solid metal key fobs and tamper proof key rings are included with all of our Key-Box key management systems.
Key-Box Pro Software License Is Included With All Key-Box Automated Key Systems At No Extra Charge!

Key-Box 9500 SC Key System is Loaded With Advanced Features


•Selected or random PIN code. Option to
 change code at cabinet(s).
•Inactivation of users.
•Validity period for users.
•Unlimited number of users


•Groups for users and keys.
•Time channels.
•Simple administration via groups.


•Time restriction.
•Searchable hidden key ID.
•Graphical key overview.
•One key in one or more cabinets.
•Free or fixed key position.


•Unlimited number of administrators.
•Adjust administrator rights.
•Selection of cabinet(s) for administration.
•Only information about own cabinet(s).
•Activities registered in log.

Key Cabinet

•Search function in display.
•Information about who has key.
•Service menu for configuration.
•Administration code with full authorization.
•Stand-alone or network.
•Automatic or fixed IP address.
•Door alarm.
•Key alarm.
•Burglar alarm.
•Choice of language.
•Connection for external reader.
•Connection for external alarm.

Event Log

•Log from PC and cabinet(s).
•Selection of what will be shown in log.
•Intelligent search function.
•Sort by date or events.
•Clear alarm indications.
•Reports via CSV file and PDF.




Modular Design Features

Designed to accommodate between 14 and 84 keys (or key sets), the innovative 9500 SC Series design allows for starting small and later expanding by adding multiples of 14 key positions (called expansion key strips) as required.
Expansion Key Strips are defined as locking or non-locking. Locking receptor strips lock the key fobs in place restricting access to authorized personnel down to the individual key. Non-locking expansion strips provide a solution for organizations requiring less security but still an audit of key usage. LED lighting indicate which keys can be taken, which keys are restricted and assist the user when returning the key to the correct location. The cabinets can be supplied with a clear polycarbonate or metal door. The control panel consists of the user interface which includes the screen, keypad and access card or biometric reader.


     9500 SC Series with biometric facial
      recognition access reader shown

 9500 SC Series
with 2 Expansion Cabinets



PC Software Administration

The 9400 SC Series is administered from the user friendly KeyWin 5 Pro software supporting a Microsoft Access or SQL database.The 9400 SC Series can communicate with the KeyWin 5-Pro software using a range of different options including Ethernet, GPRS, RS485, RS232 and modem. Multiple systems can be networked together over a local or wide area network to provide accountability for a limitless number of keys administrated from multiple PC workstations running the KeyWin 5-Pro software.


Optional User Identification

The 9500 SC Series can support any type of optional access control device required to identify a user to the key system. Supported devices include RFID proximity readers from all leading access control manufacturers, magstripe, barcode and biometric technologies such as fingerprint, facial etc.



Cabinet Dimensions: 746 x 730 x 140 mm
Weight: 30 kg
Power Supply: Input: AC120-240V
                          Output: VDC
Battery Backup: DC12V 3.2Ah (24hours)
Power Consumption: 65W max/0.3A
Cabinet Material: Steel
Color Options: Light Grey Powder Coated


Operating Temp: Ambient For Indoor Use Only
Mounting: Wall or Cabinet stand mounted
Key Positions: 14-84
Receptor Strip Support: Locking, Non Locking,
Users per systems: 10,000 plus
Communications: Ethernet, GPRS, RS485, RS232, Modem
Reader Interface: Wieguard
Door Material: Solid Metal or optional Clear Polycarbonate
